Area
Area units
Definition
Square unit
The
square unit
is the area of the square which side is the unit length, that is to say the multiplication of unit length by it itself.
Definition
Common units of area
The most common units of area are the squares of the length units:
square millimetres \(\left(\mathrm{mm}^{2}\right)\)
square centimetres \(\left(\mathrm{cm}^{2}\right)\)
square metres \(\left(\mathrm{m}^{2}\right)\)
square kilometres \(\left(\mathrm{km}^{2}\right)\)
hectares (ha).
Example
onvertir \(1 \mathrm{~cm}^{2}\) en \(\mathrm{~mm}^{2}\)
Answer
$$\begin{aligned}1 \mathrm{~cm}^{2}&= 1 \mathrm{~cm} \times 1 \mathrm{~cm}\\ &=10 \mathrm{~mm} \times 10 \mathrm{~mm}\quad \text{as }1 \mathrm{~cm}=10 \mathrm{~mm}\\ &=10\times 10 \times \mathrm{~mm} \times \mathrm{~mm}\quad \\ &=100 \mathrm{~mm}^{2}\end{aligned}$$
Proposition
Table of conversion
\(\begin{aligned}&1 \mathrm{~cm}^{2}=10 \mathrm{~mm} \times 10 \mathrm{~mm}=100 \mathrm{~mm}^{2}\\&1 \mathrm{~m}^{2}=100 \mathrm{~cm} \times 100 \mathrm{~cm}=10\,000 \mathrm{~cm}^{2}\\&1 \mathrm{~ha}=100 \mathrm{~m} \times 100 \mathrm{~m}=10\,000 \mathrm{~m}^{2}\\&1 \mathrm{~km}^{2}=1000 \mathrm{~m} \times 1000 \mathrm{~m}=1\,000\,000 \mathrm{~m}^{2} \text { or } 100 \mathrm{ha}\end{aligned}\)
Example
Convert \(10.5\mathrm{~m}^2\) to \(\mathrm{cm}^2\)
Solution 1:
\(\begin{aligned}[t]10.5\mathrm{~m}^2 &=10.5\times 10\,000\mathrm{~cm}^2 \\&=105\,000\mathrm{~cm}^2\end{aligned}\)
Solution 2:
\(10\virgule 5\mathrm{~m}^2 =105\,000\mathrm{~cm}^2\)
Definition
Definition
Area
The area of a figure is the number of square units it contains.
Example
Find the area of the red figure :
Answer
\(\begin{aligned}[t]A&=7\times \textcolor{colordef}{\blacksquare}\\&=7\times \textcolor{colordef}{1 \mathrm{~cm}^2}\\&=7\mathrm{~cm}^2\\\end{aligned} \)
Area of usual figures
Proposition
Area formulae
Name
Shape
Area
Rectangle
\( A= l \times w \)
Square
\(\begin{aligned} A&= l^2\end{aligned}\)
Parallelogram
\( A= b\times h\)
Triangle
\(A=\dfrac{b\times h}{2}\)
Circle
\(A=\pi r^2\)
Trapezium
\( A= \dfrac{a+b}{2}\times h\)
Area of composite figures
Definition
Composite figure
A
composite figure
is made up of simple geometric shapes.
Method
Find the area of a composite figure
To find the area of a composite figure,
divide it into simple, nonoverlapping figures
find the area of each simpler figure
add the areas together to find the total area of the composite figure
Example
Answer
\(\begin{aligned}[t]A &= \text{Area of square} + \text{Area of triangle}\\ &= c\times c + \frac{b \times h }{2}\\ &= 4\time 4 + \frac{3\times 4 }{2}\\ &= 22 \mathrm{~cm}^2\\\end{aligned}\)
